Product Details:

Place of Origin: CHINA
Brand Name: ZMKJ
Model Number: 10x10x0.5mmt

Payment & Shipping Terms:

Minimum Order Quantity: 1pcs
Price: by case
Packaging Details: single wafer package in 100-grade cleaning room
Delivery Time: 1-6weeks
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 1-50pcs/month
Get Best Price Contact Now

Detail Information

Material: SiC Single Crystal 4H-N Type Grade: Dummy /Production Grade
Thicnkss: 0.5MM Suraface: Polished
Application: Bearing Test Diameter: 10x10x0.5mmt
Color: Dark Brown
High Light:

silicon on sapphire wafers

,

sic wafer

Product Description


Customzied size/10x10x0.5mmt/2inch/3inch/4inch/6inch 6H-N/4H-SEMI/ 4H-N SIC ingots/High purity 4H-N 4inch 6inch dia 150mm silicon carbide single crystal (sic) substrates wafersS/ Customzied as-cut sic wafers

About Silicon Carbide (SiC)Crystal

Silicon carbide (SiC), also known as carborundum, is a semiconductor containing silicon and carbon with chemical formula SiC. SiC is used in semiconductor electronics devices that operate at high temperatures or high voltages, or both.SiC is also one of the important LED components, it is a popular substrate for growing GaN devices, and it also serves as a heat spreader in high-power LEDs.

1. Description
Property4H-SiC, Single Crystal6H-SiC, Single Crystal
Lattice Parametersa=3.076 Å c=10.053 Åa=3.073 Å c=15.117 Å
Stacking SequenceABCBABCACB
Mohs Hardness≈9.2≈9.2
Density3.21 g/cm33.21 g/cm3
Therm. Expansion Coefficient4-5×10-6/K4-5×10-6/K
Refraction Index @750nm

no = 2.61
ne = 2.66

no = 2.60
ne = 2.65

Dielectric Constantc~9.66c~9.66
Thermal Conductivity (N-type, 0.02 ohm.cm)

a~4.2 W/cm·K@298K
c~3.7 W/cm·K@298K


Thermal Conductivity (Semi-insulating)

a~4.9 W/cm·K@298K
c~3.9 W/cm·K@298K

a~4.6 W/cm·K@298K
c~3.2 W/cm·K@298K

Band-gap3.23 eV3.02 eV
Break-Down Electrical Field3-5×106V/cm3-5×106V/cm
Saturation Drift Velocity2.0×105m/s2.0×105m/s



4 inch n-doped 4H Silicon Carbide SiC Wafer

 High purity 4inch diameter Silicon Carbide (SiC) Substrate Specification




Customized Size Silicon Carbide Wafer 10x10x0.5mm 4H-N SiC Crystal Chips 1Customized Size Silicon Carbide Wafer 10x10x0.5mm 4H-N SiC Crystal Chips 2Customized Size Silicon Carbide Wafer 10x10x0.5mm 4H-N SiC Crystal Chips 3

CATALOGUE   COMMON  SIZE




4H-N Type / High Purity  SiC wafer/ingots
2 inch 4H N-Type SiC wafer/ingots
3 inch 4H N-Type SiC wafer
4 inch 4H N-Type SiC wafer/ingots
6 inch 4H N-Type SiC wafer/ingots


4H Semi-insulating /  High Purity SiC wafer

2 inch 4H Semi-insulating SiC wafer
3 inch 4H Semi-insulating SiC wafer
4 inch 4H Semi-insulating SiC wafer
6 inch 4H Semi-insulating SiC wafer


6H N-Type SiC wafer
2 inch 6H N-Type SiC wafer/ingot

 Customzied size for 2-6inch


About ZMKJ Company

ZMKJ can provides high quality single crystal SiC wafer ( Silicon Carbide ) to electronic and optoelectronic industry . SiC wafer is a next generation semiconductor material , with unique electrical properties and excellent thermal properties , compared to silicon wafer and GaAs wafer , SiC wafer is more suitable for high temperature and high power device application . SiC wafer can be supplied in diameter 2-6 inch , both 4H and 6H SiC , N-type , Nitrogen doped , and semi-insulating type available . Please contact us for more product information .


Our Relation  Products
Sapphire wafer& lens/  LiTaO3 Crystal/  SiC wafers/ LaAlO3 / SrTiO3/wafers/ Ruby Ball

Customized Size Silicon Carbide Wafer 10x10x0.5mm 4H-N SiC Crystal Chips 4
