Introduction of Sapphire Wafers:

   Sapphire wafers are primarily used in specialized fields such as light-emitting diode (LED) manufacturing. Sapphire possesses characteristics such as high hardness, high melting point, and excellent electrical insulation. Its hardness is second only to that of diamond, which makes sapphire wafers difficult to process, but also ensures exceptional stability and durability during use. Sapphire exhibits excellent optical transparency, particularly in the ultraviolet to near-infrared wavelength range, giving it broad applications in the field of optics. In LED manufacturing, sapphire wafers serve as substrate materials, providing a high-quality crystal growth environment that helps improve the luminous efficiency and stability of LEDs.The 12-inch sapphire substrate is an ultra-large single-crystal wafer made from high-purity aluminum oxide (Al₂O₃), with a diameter of 300 millimeters (12 inches). These substrates represent a major advancement in sapphire crystal growth and wafer processing technology, enabling high-throughput manufacturing for next-generation applications such as micro-LED displays, radio-frequency (RF) devices, power electronics, and optical components.

Applications of Sapphire Wafers:

LED Lighting and Displays: Sapphire wafers are the core substrate material used in LED chip manufacturing. They provide an ideal lattice-matching environment for the growth of light-emitting materials such as gallium nitride (GaN), thereby enhancing luminous efficiency and operational stability.

Consumer Electronics: Sapphire is used for smartphone screens, smartwatch surfaces, and earphone housings to improve wear resistance and scratch protection.

Lens Protection: As camera lens covers, sapphire provides superior hardness and optical clarity, ensuring durability and image precision.

Professional Optics :Ideal for manufacturing optical windows, lenses, prisms, lasers, and sensors used in professional and industrial systems.

Luxury Industry: Renowned for its exceptional scratch resistance and optical transparency, sapphire is widely used in premium watch dials and crystals.

Medical Instruments: Sapphire components are used in high-end medical equipment, including optical lenses, microscopes, and laser systems, where precision, durability, and optical performance are critical.

Parameters of ZMSH Saphire Wafers:

Advantages of Sapphire Wafers:

• High Hardness & Wear Resistance: With a Mohs hardness of 9, second only to diamond, it resists scratches and abrasion, making it ideal for highly reliable cover plates and window applications.

• Broad-Spectrum Optical Transmission: Exhibits high transparency across the ultraviolet to near-infrared range, covering ~200–5500 nm, suitable for LEDs, lasers, and optical sensing.

• High-Temperature Resistance & Thermal Stability: Boasts a high melting point of ~2045°C, maintaining stability under extreme high-temperature processes and harsh environments.

• Excellent Electrical Insulation & Dielectric Stability: Offers outstanding electrical insulation properties, with a dielectric constant of 9.3–11.5 and dielectric loss <0.0001 (stable at high frequencies).

• Strong Chemical Inertness: Resistant to acids, alkalis, and oxidation, ensuring long-term reliability.

• Diverse Sizes & Processing Options: Mass-produced in 2–8-inch sizes, with expansion to 12-inch; available in

double-sided polishing, nano-level surface roughness (e.g., Ra ≤ 0.3 nm), and precision finishing such as anti-reflective coatings and metallization.

ZMSH Introduction and Related Product Recommendation:

   ZMSH is a high-tech enterprise specializing in the research, production, processing, and sales of Semiconductor substrates and optical crystal materials. ZMSH products are widely used in Semiconductor, and optical electronics, consumer electronics, the military industry, as well as the fields of laser and optical communication. ZMSH products including optical windows, semi wafers, color glass filters and prisms have achieved a good sales record both in China and overseas market, the products have been exported to over 20 countries in EU, the USA, Japan,Isreal ,South Korea and South Asia Etc.

DSP 8inch 6inch Dia200mm monocrystalline Al2O3 Sapphire Substrate Prime Wafers for your reference:

Q&A:

Q: What is a sapphire wafer?

A: A sapphire wafer is a single-crystal substrate made from aluminum oxide (Al₂O₃). It’s one of the hardest, most thermally stable, and optically transparent materials used in the semiconductor and optoelectronics industries.

Q: What is the difference between sapphire and silicon wafers?

A: sapphire wafers and silicon wafers are both key materials in the semiconductor industry, but they serve very different purposes because their physical, electrical, and optical properties are fundamentally distinct. Sapphire wafers are used where optical clarity, insulation, and durability are needed — such as in LEDs, RF, and optics.

Silicon wafers are used where electronic conductivity and integration are needed — such as in microchips, CPUs, and sensors.

Q: What size are sapphire wafers?

A: Sapphire wafers typically range from 2 to 12 inches in diameter, with thicknesses between 100 µm and 1.6 mm, depending on the device type, application, and polishing level.
