Thermal Oxide Layer SiO2 Wafer Thickness 20um MEMS Optical Communication System
Product Details:
| Place of Origin: | China |
| Brand Name: | ZMSH |
| Model Number: | Ultra-thick silicon oxide wafer |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5 |
|---|---|
| Delivery Time: | 2-4 weeks |
| Payment Terms: | T/T, |
|
Detail Information |
|||
| Boiling Point: | 2,230° C (4,046° F) | SMILES: | O=[Si]=O |
|---|---|---|---|
| Oxide Thickness Tolerance: | +/- 5% (both Sides) | Refractive Index: | Approximately 1.44 |
| Thermal Conductivity: | Around 1.4 W/(m·K) @ 300K | Molecular Weight: | 60.09 |
| Application Areas: | Semiconductor Manufacturing, Microelectronics, Optical Devices, Etc. | Refractive Index: | 550nm Of 1.4458 ± 0.0001 |
| High Light: | Optical Communication System Silicon Dioxide Wafer,Thermal Oxide Layer SiO2 Wafer,20um SiO2 Wafer |
||
Product Description
SiO2 wafer Thermal Oxide Laver Thickness 20um+5% MEMS Optical Communication System
Product Description:
The SIO2 silicon dioxide wafer serves as a foundational element in semiconductor manufacturing. Featuring a thickness ranging from 10μm to 25μm, this crucial substrate is available in 6-inch and 8-inch diameters, ensuring versatility for various applications. Primarily, it acts as an essential insulating layer, playing a pivotal role in microelectronics by providing high dielectric strength. Its refractive index, approximately 1.4458 at 1550nm, ensures optimal performance across diverse applications.
Renowned for its uniformity and purity, this wafer stands as an ideal choice for optical devices, integrated circuits, and microelectronics. Its properties facilitate precise device fabrication processes and support technological advancements. Beyond its foundational role in semiconductor manufacturing, it extends its reliability and functionality to a spectrum of applications, guaranteeing stability and efficiency.
With its exceptional attributes, the SIO2 silicon dioxide wafer continues to drive innovations in semiconductor technology, enabling advancements in fields such as integrated circuits, optoelectronics, and sensor technologies. Its contributions to cutting-edge technologies underscore its significance as a cornerstone material in the realm of semiconductor production.
Features:
- Product Name: Semiconductor Substrate
- Refractive Index: 550nm Of 1.4458 ± 0.0001
- Boiling Point: 2,230° C (4,046° F)
- Application Areas: Semiconductor Manufacturing, Microelectronics, Optical Devices, Etc.
- Thickness: 20um,10um-25um
- Molecular Weight: 60.09
- Semiconductor Material: Yes
- Substrate Material: Yes
- Applications: Semiconductor Manufacturing, Microelectronics, Optical Devices, Etc.
Technical Parameters:
| Parameter | Specification |
| Thickness | 20um,10um-25um |
| Density | 2533 Kg/m-3 |
| Oxide thickness tolerance | +/- 5% (both Sides) |
| Application Areas | Semiconductor Manufacturing, Microelectronics, Optical Devices, Etc. |
| Melting Point | 1,600° C (2,912° F) |
| Thermal Conductivity | Around 1.4 W/(m·K) @ 300K |
| Refractive Index | Approximately 1.44 |
| Molecular Weight | 60.09 |
| Coefficient of Expansion | 0.5 × 10^-6/°C |
| Refractive Index | 550nm Of 1.4458 ± 0.0001 |
| Ultra-thick silicon oxide wafer | Applications |
| Surface oxidation | Ultra-thin wafer |
| Thermal Conductivity | Around 1.4 W/(m·K) @ 300K |
Applications:
- Thin-Film Transistors: Employed in the production of TFT devices.
- Solar Cells: Used as a substrate or insulating layer in photovoltaic technology.
- MEMS (Micro-Electro-Mechanical Systems): Crucial for MEMS device development.
- Chemical Sensors: Utilized for sensitive chemical detection.
- Biomedical Devices: Employed in various biomedical applications.
- Photovoltaics: Supports solar cell technology for energy conversion.
- Surface Passivation: Aids in semiconductor surface protection.
- Waveguides: Used in optical communication and photonics.
- Optical Fibers: Integral in optical communication systems.
- Gas Sensors: Employed for gas detection and analysis.
- Nanostructures: Used as a substrate for nanostructure development.
- Capacitors: Utilized in various electrical applications.
- DNA Sequencing: Supports applications in genetic research.
- Biosensors: Used for biological and chemical analysis.
- Microfluidics: Integral in microfluidic device fabrication.
- Light-Emitting Diodes (LEDs): Supports LED technology in various applications.
- Microprocessors: Essential for the production of microprocessor devices.
Customization:
Brand Name: ZMSH
Model Number: Ultra-thick silicon oxide wafer
Place of Origin: China
Our Semiconductor Substrate is designed with high thermal conductivity, surface oxidation and ultra-thick silicon oxide wafer. It has a thermal conductivity of around 1.4 W/(m·K) @ 300K and melting point of 1,600° C (2,912° F). The boiling point is 2,230° C (4,046° F) and the orientation is <100><11><110>. The molecular weight of this substrate is 60.09.
