Material: Sapphire Substrate Grade Orientation: C-AXIS
Thickness: 300-500um(other Thickness Ok) Surface: DSP
TTV: <10um BOW: <10um
Warp: <10um Package: 100 Grade Cleaning Room By Vacuum Package
Customize: Acceptable
High Light:

Sapphire Wafers For Epitaxial Growth

,

C Plane Sapphire Substrate

,

500um University Wafer Sapphire

Product Description

3inch 300um 500um sapphire wafers sapphire substrate C-plane for epitaxial growth

Ultra-thin  2inch sapphire  DSP wafers  thickness 100um 0.1mm

2inch 100um Ultra Thin sapphire wafers 0.1mm Thickness C-plane DSP Sapphire wafer





Why Sapphire?



1. Sapphire has a high optical transmittance, so it is widely used as microelectronic tube dielectric material, ultrasonic conduction element, waveguide laser cavity, and other optical elements, as window materials for infrared military devices, space vehicles, high-intensity lasers and optical communications.

2. Sapphire has high rigidity, high strength, high working temperature, abrasion resistance, corrosion resistance characteristics, so sapphire substrate is often used in harsh environments, such as boiler water gauge (high-temperature resistance), commodity bar code scanner, bearing, and other precision manufacturing (wear resistance), coal, gas, well detection sensors and detector windows (anti-corrosion).

3. Sapphire has the characteristics of electrical insulation, transparency, good thermal conductivity, and high rigidity, so it can be used as the substrate material of integrated circuits, such as LED and microelectronic circuits, ultra-high-speed integrated circuit.



The Detail for 3inch C-axis wafers


Size: 3inch  DSP-0.5-C-Sapphire

Material: KY Sapphire Al2O3 single crystal without bubble;color ;

Orientation:R-cut,R-axis off 0.0+/-0.1°;
Diameter: 76.2 +/-0.2mm ;

Thickness:500 ± 15 um ;
OF Flat:22.0 +/- 1.0 mm ;
OF orientation: A-axis
Surface: SSP Epi-ready Polished ;
TTV<= 10um ;BOW<= 10um ; Warp<= 10 um ;
Front Surface Roughness (Ra) Ra <= 0.3 nm;

Back Surface Roughness (Ra)  Ra = 0.3 +/-0.2um ;
Edge: from 1mm ;



General  Other Size Sheet  on Stocks


 Standard wafer
2 inch C-plane sapphire wafer SSP/DSP
0.1mm,0.175mm, 0.2mm; 0.3mm,0.4mm,0.5mm
3 inch C-plane sapphire wafer SSP/DSP
0.43mm,0.5mm;
4 inch C-plane sapphire wafer SSP/DSP
0.25mm,0.3mm,0.4mm,0.5mm,0.65mm
6 inch C-plane sapphire wafer SSP/DSP
1.0mm,1.3mm, 0.8mm
Special Orientation
A-plane (1120) sapphire wafer
R-plane (1102) sapphire wafer
M-plane (1010) sapphire wafer
All on stocks
C-axis with a 0.5°~ 10° offcut, toward A-axis or M-axis
Other customized orientation

Customized Size
10x10x0.5mm sapphire wafer
20x20x0.5mm sapphire wafer
Ultra thin (100um) 2inch sapphire wafer
8 inch sapphire wafer




Patterned Sapphire Substrate (PSS)
2 inch C-plane PSS
4 inch C-plane PSS
