Product Details:

Place of Origin: CHINA
Brand Name: JLSY
Model Number: JLX-1700

Payment & Shipping Terms:

Minimum Order Quantity: 1pc
Price: By requirement
Packaging Details: The wooden case
Delivery Time: 1-2month after order
Payment Terms: 40% deposit T/T, 60%before the delivery.
Supply Ability: 10pcs/month
Get Best Price Contact Now

Detail Information

Item: High Temperature Furnace Max Temperature: Up To1800°
Heat Elent: Silicon Molybdenum Rod Heat Rate: 20-30°C/min
Applicaiton: Semi-wafer Metal Annealing, Power: 220Vor 380V
High Light:

light transmittance meter

,

uv transmittance meter

Product Description





1700-2600° high temperature furnace, sapphire annealing furnace, tube furnace, atmosphere furnace, hydrogen furnace, vacuum furnace, three-layer constant temperature and humidity chamber, mold test chamber, high and low temperature test chamber, carbon tube furnace, hot pressing furnace





Product introduction: jlx-1700 aerobic annealing furnace is mainly used in the laboratory of institutions of higher learning, scientific research institutes, etc., providing 1700 ° C high temperature test environment, applied in semiconductors such as silicon carbide (SiC); silicon wafers(Si), gallium arsenide (GaAs ), GaN, sapphire(Al2O3), aerospace, microelectronics, nanotechnology and other new materials.



Product description:

The JLX series muffle furnace is developed for the daily application of factories and laboratories. The excellent roasting effect, modern exterior design and high reliability are the outstanding features of this type of electric furnace. The product uses high-quality silicon carbon rod as heating element, and the furnace adopts imported alumina polycrystalline fiber material. Microcomputer control, easy to operate, programmable, automatic heating, automatic insulation, automatic cooling.

Wafer Annealing Scientific Lab Equipment 1800°C High Temperature Furnaces 0

Features:

1. The furnace adopts Japan's energy-saving technology, which saves 30% compared with the traditional electric furnace;



2. The heating element is high-quality molybdenum disilicide, with large surface load and long service life;



3, sturdy and durable vacuum reinforced fiber module, double-layer furnace shell structure is stable, with air cooling layer, equipped with cooling fan;



4. There is a smoke exhaust passage at the top to facilitate the discharge of impurities and corrosive gases without affecting the service life of the equipment;



5, the heating rate is fast up to 30 ° C / min, can also accurately control 0.5 ° C / min



6, the button mechanical life is not less than 200,000 times (1200 times / hour)



7, using multi-stage program temperature control, programmable, automatic temperature rise, insulation, digital display ammeter;



8. Optional paperless recorder to record, store and display current or historical temperature curves, or transfer them to a computer via a USB flash drive.



9. Optional Xinite intelligent temperature control software for full monitoring and operation through the computer



Wafer Annealing Scientific Lab Equipment 1800°C High Temperature Furnaces 1Wafer Annealing Scientific Lab Equipment 1800°C High Temperature Furnaces 2



Items Size mm Maximum temperature Heating element Heating rate power Voltage
JLS1000-20



300*200*200

1000 Resistance wire







20 °C/min

220V 3kw
JLS1400-20 1400 Silicon carbon rod 220V 5kw
JLS1800-20 1800 Silicon molybdenum rod 380V 10kw
JLS1000-40



400*300*300

1000 Resistance wire







20 °C/min

22OV 6kw
JLS1400-40 1400 Silicon carbon rod 220V380V 10kw
JLS1800-40 1800 Silicon molybdenum rod 380V 120kw
JLS1000-50



500*400*400

1000 Resistance wire







20 °C/min

220V380V 15kw
JLS1400-50 1400 Silicon carbon rod 380V 18kw
JLS1800-50 1800 Silicon molybdenum rod 380V

25kw









































About the Factory

Wafer Annealing Scientific Lab Equipment 1800°C High Temperature Furnaces 3

     The factory has professional team support from product development to production and processing, assembly

and commissioning, and time service. Has many years of perfect technology, tooling, testing equipment

and quality management system. All products are produced in accordance with ISO9001; 2000 quality system.



Products are highly recognized and adopted in the fields of aviation, aerospace, shipbuilding, military, universities,

research institutes, electronics, automotive, medicine, communications, chemical, electrical, instrumentation, 3D printing, etc.

They are highly recognized in mainland China. The company has sapphire crystal annealing furnace, tube furnace,

atmosphere furnace, hydrogen furnace, constant temperature and humidity furnace, hot pressing furnace,

high temperature furnace etc.
