High Purity Al2O3 99.999% Sapphire Substrate Wafer Carrier DSP SSP
Product Details:
| Place of Origin: | China |
| Brand Name: | ZMSH |
| Certification: | ROHS |
| Model Number: | Sapphire wafer substrate |
Payment & Shipping Terms:
| Minimum Order Quantity: | 25pcs |
|---|---|
| Price: | usd10/pc |
| Packaging Details: | 25 wafers in one cassette |
| Delivery Time: | 3 days |
| Supply Ability: | 50000+pcs per month |
|
Detail Information |
|||
| Substrate Type: | 2inch C-plane （0001）SSP 0.43mm | Ra: | <0.3nm |
|---|---|---|---|
| Bow: | -10 μm ≤ BOW ≤ 0 | Warp: | <20μm |
| Surface Orientation: | ±0.5° | Material: | Al2O3 99.999% |
| Name: | Sapphire Wafer Substrate Carrier | TTV: | <5μm |
| High Light: | Sapphire Substrate Wafer Carrier,Al2O3 99.999% Sapphire Substrate,M-Plane Sapphire Substrate |
||
Product Description
High Purity Al2O3 99.999% Sapphire Substrate Wafer Carrier DSP SSP
Product Description:
Sapphire Substrate is a high-quality single-crystal substrate carrier made of Al2O3 material with an ultra-low TTV of less than 5 μm. It is available in both C-plane and M-plane orientation, providing excellent parallelism of 3 arcsecs. It is the perfect choice for sapphire windows and sapphire wafer applications. It is perfect for high-end optical, optoelectronic, and semiconductor device applications. With its outstanding performance, Sapphire Substrate is the ideal choice for demanding applications.
Features:
- Product Name: Sapphire Substrate
- Surface Orientation: ±0.5° C-plane and M-plane
- TTV: <5μm
- Material: Al2O3 99.999%
- Warp: <20μm
- Bow: <20μm
- Applications: Sapphire Windows and Sapphire Substrates
Applications:
ZMSH's Sapphire Substrate is the perfect choice for your wafer-level device needs. Our sapphire wafer has a model number of Sapphire wafer, which is made in China and features a surface orientation of ±0.5°, a clear aperture of >90%, a surface roughness of Ra<0.5nm, a surface quality of single side polished, and a perpendicularity of 3 arc sec. With its superior quality and reliable performance, it is the perfect substrate for your wafer-level device needs.
Technical Parameters:
| Parameters | Description |
|---|---|
| Name | Sapphire Wafer Substrate Carrier |
| Material | Al2O3 99.999% |
| Substrate Type | Single Crystal |
| Size | 1inch 2inch 3inch 4inch 6 Inch 8inch 12inch |
| Thickness | 0.1-5mm |
| Bow | <20μm |
| TTV | <5μm |
| Flatness | λ/10@633nm |
| Parallelism | 3 Arc Sec |
| Clear Aperture | >90% |
| Keywords | Sapphire wafer, sapphire windows, C-plane M-plane, wafer fabrication, crystal growth, opto-electronic, substrate carrier, single crystal |
2inch C-plane (0001)SSP 0.43mm Single side polished Sapphire substrates
| No | Properties | Target | Tolerance | ||||||||||||||||||||||
| 1 | Diameter | 50.8mm | ± 0.1mm | ||||||||||||||||||||||
| 2 | Thickness | 430μm | ±15μm | ||||||||||||||||||||||
| 3 | Surface orientation of C-plane | off C-axis to M0.2° | ± 0.1° | ||||||||||||||||||||||
| 4 | Primary flat length | 16mm | ±11mm | ||||||||||||||||||||||
| 5 | Primary flat orientation | A-plane(11-20) | ±0.1° | ||||||||||||||||||||||
| 6 | Back side Roughness | 0.8~1.2um | |||||||||||||||||||||||
| 7 | Front side Roughness | <0.3nm | |||||||||||||||||||||||
| 8 | Wafer edge | R-type | |||||||||||||||||||||||
| 9 | Total Thickness Variation, TTV | ≤ 10μm(LTV≤5μm,5*5) | |||||||||||||||||||||||
| 10 | SORI | ≤10μm | |||||||||||||||||||||||
| 11 | Bow | -10 μm ≤ BOW ≤ 0 | |||||||||||||||||||||||
| 12 | Laser Mark | N/A | |||||||||||||||||||||||
| Package | 25 wafers in one cassette | ||||||||||||||||||||||||
| Trace ability | Wafers shall be traceable with respect to cassette number | ||||||||||||||||||||||||
We specialize in providing customized services for ZMSH Sapphire Substrate with high Clear Aperture and Surface Roughness of <0.5nm, and Bow and Warp of <20μm, available in C-plane. A-plane, M-plane, R-plane 2inch,3inch, 4inch 6inch, 8inch 12inch.
