SSP DSP VGF N-Type P-Type InP Wafers High Electron Mobility / Thermal Conductivity

Product Description:

Our InP (Indium Phosphide) wafers are renowned for their low defect density and high performance, widely used in optoelectronics and microelectronics. These wafers are crafted using precision growth techniques, ensuring the material's high purity and excellent crystal structure, significantly reducing defect density, and enhancing device performance and reliability.InP available in diameters from 2 to 6 inches, our wafers meet the needs of various applications. We also offer a range of surface treatment options, including polishing, etching, and oxidation, to accommodate specific process requirements. To ensure product consistency and reliability, we implement stringent quality control procedures and provide detailed product inspection reports. Opting for our low-defect InP wafers ensures exceptional performance and stable quality, helping your products stand out in the highly competitive market.

Features:

• High Thermal Conductivity: InP exhibits relatively high thermal conductivity, aiding in effective heat dissipation in electronic devices.
• Chemical Stability: InP is chemically stable and highly resistant to many chemical substances in the environment.
• Compatibility: InP can form heterostructures with other III-V group materials such as GaAs and InGaAs, which is crucial in manufacturing high-performance optoelectronic and microelectronic devices.
• Mechanical Strength: Although more brittle than silicon, InP still has sufficient mechanical strength to withstand the pressures of manufacturing and packaging processes.
• Radiation Resistance: InP has strong resistance to radiation, making it suitable for use in harsh environments, such as space applications.
• High Bandgap Engineering Adaptability: The material properties of InP can be manipulated for specific applications through bandgap engineering.
• High Bandgap Engineering Adaptability: The material properties of InP can be manipulated for specific applications through bandgap engineering.

Technical Parameters:

Applications:

• Optical Sensing: InP’s optical properties make it an ideal material for creating sensors that can detect a variety of environmental parameters, such as temperature, pressure, and chemical composition.
• Fiber Lasers: InP is used in the production of fiber lasers, which are known for their high efficiency and ability to produce a high-quality beam. These lasers are used in material processing, medical applications, and telecommunications.
• Night Vision Technology: The infrared transparency of InP makes it a suitable material for applications in night vision technology, where it is used to enhance visibility in low-light conditions.
• Satellite Communication: InP’s radiation resistance and high-frequency performance make it an excellent choice for satellite communication applications, where it is used in the fabrication of transistors and other electronic components.
• Optical Disc Storage: InP can be used in the manufacture of optical disc storage devices due to its ability to efficiently emit and detect light.

Customization:

ZMSH provides customization services for Gallium Nitride Wafer with high electron mobility and semiconductor properties. Our Gallium Nitride Wafer includes Model Number InP and is manufactured with quality components from China. Its storage conditions require a temperature of 20-25°C and humidity of ≤60%. The etch pit density is ≤1E2/cm2 and the flatness of the wafer surface is ≤0.5 μm. We offer two types of polishing: DSP and SSP. The doping element used for doping includes antimony (Sb), indium (In), phosphorus (P), etc.
