Product Details:

Place of Origin: China
Brand Name: ZMSH
Model Number: Ce+ doped YAG

Payment & Shipping Terms:

Minimum Order Quantity: 500g
Get Best Price Contact Now

Detail Information

Thermal Expansion: E7.8x10-6 /K <111> Conduction Type: N
Density: 4.56g/cm3 Crystal Structure: Cubic Crystal System
Available Surface Area: 90% Refractive Index: 1.82
Lattice Constant: 12.01Å Melt Point: 1970°C
High Light:

Ce+ Doped YAG Crystal


Detector YAG Crystal


Ce+ Doped YAG Synthetic Gem Stone

Product Description

Product Description:

Ce:YAG single crystal is renowned for its outstanding optical performance and stability. It efficiently converts the energy of incident particles into light signals, boasting a high light yield (20000 photons/MeV) and a rapid light decay time (70ns), making it excel in particle detection.


Furthermore, Ce:YAG single crystal exhibits exceptional thermomechanical properties, enabling it to function in extreme environments. With a peak light emission wavelength of 540nm, it perfectly matches the receiving wavelengths of traditional photomultiplier tubes (PMT) and silicon photodiodes (PD).


Ce:YAG single crystals find extensive applications in electron microscopy, beta and X-ray counting, electron and X-ray imaging screens, among other fields. Its exceptional performance and versatility make it the ideal choice for particle detection and imaging applications.

Ce:YAG single crystal provides a reliable, high-performance scintillation material solution for your scientific research and engineering needs.

Ce+ Doped YAG Crystal Glow Detector Luminescence Thermal Stability 0


  • Product Name: Synthetic Gem Stone
  • Engineering stone, Artificial Marble Stone, Diamond Dressing Stone
  • Density: 4.56g/cm3
  • Refractive index: 1.82
  • Crystal structure: Cubic Crystal System
  • Lattice constant : 12.01Å
  • Conduction type: N

Technical Parameters:

Parameter Value
Melt point 1970°C
Available surface area 90%
Crystal structure Cubic Crystal System
Thermal expansion (C-1) 8.5*10-6
Density 4.56g/cm3
Conduction type N
Lattice constant 12.01Å
Refractive index 1.82
Thermal conductivity (w/m/k) 14W/m/K, 20°C 10.5W/m/K, 100°C
Thermal expansion E7.8x10-6 /K <111>


  1. Nuclear Medicine Imaging: Ce:YAG is used in positron emission tomography-computed tomography (PET-CT) and single-photon emission computed tomography-computed tomography (SPECT-CT) for precise localization and analysis of radiopharmaceutical tracers.
  2. Particle Physics Experiments:  Ce:YAG serves as a scintillation detector in high-energy particle physics experiments, such as at the Large Hadron Collider (LHC), to detect optical signals generated by high-energy particle collisions.
  3. Radiation Therapy: Ce:YAG employed for precise measurement and delivery of radiation doses in cancer treatment and radioisotope therapy.
  4. Nuclear Industry:Ce:YAG utilized for radiation detection and measurement in nuclear power plants and radioisotope production facilities.
  5. Electron Microscopy: Ce:YAG used as a sample fluorescence labeling material to enhance contrast in electron microscope images, aiding in the observation of cells and tissues.
  6. Radiation Counting:Ce:YAG applied in radiation dose measurement, radiographic imaging, nuclear physics experiments, and radiation therapy as a scintillation detector.
  7. Laser Measurements: Employed in laser radar and optical sensor applications to measure distance and velocity.
  8. Nuclear Physics Research:Ce:YAG is used for the detection of charged particles produced in high-energy nuclear reactions, contributing to nuclear physics research.


Synthetic Gem Stone is a premium product from ZMSH that features Ce+ doped YAG from China with N conduction type. It has an excellent thermal conductivity of 14W/m/K at 20°C and 10.5W/m/K at 100°C with an impressive melt point at 1970°C. It offers a single crystal purity of 99.99% with thermal expansion of 8.5*10-6. It is perfect for applications such as flamed granite stone, cultured stone brick, and colorful quartz stone.


Support and Services:

We provide technical support and services for Synthetic Gem Stone products. Our experienced customer service team can provide you with help and advice on product selection, installation, maintenance and repair. We have a range of online resources, including product manuals, technical documents, online tutorials and FAQs, so you can get up and running quickly. If you need more help, our engineers are available to answer your questions by phone or email.


Packing and Shipping:

Packaging and Shipping

Synthetic gem stones are packaged and shipped with care in order to minimize any damage during transit. The packages are made of strong cardboard and are sealed with bubble wrap inside for extra protection. All packages are shipped via a trusted shipping service and are typically delivered within 5-7 business days.
