OEM Dia 25.4mm Single Crystal Ge optical lens

OEM Dia 25.4mm Single Crystal Ge optical lens

Product Details:

Place of Origin: China
Brand Name: zmkj
Model Number: dia25.4*3mmt

Payment & Shipping Terms:

Minimum Order Quantity: 10pcs
Price: by case
Packaging Details: single wafer container or customzied container box under cleaning room
Delivery Time: 2-4weeks
Payment Terms: T/T, Western Union
Supply Ability: 1000pcs/month
Get Best Price Contact Now

Detail Information

Material: Ge Single Crystal Ge Window Application: Infrared Optics Elements
Type: Un-doped Resistivity: >30Ω
Orientation: <100> SIZE: DIA25.4*3.0mmt
Surface: Double Side Polished OEM: Ok
High Light:

Single Crystal Gallium Nitride Wafer

,

Dia 25.4mm Gallium Nitride Wafer

,

OEM Gallium Nitride Wafer

Product Description

dia25.4mm Ge windows Single Crystal Germanium Ge Wafer for Semiconductor device



Product Description

ZMKJ  is a worldwide supplier of single crystal  Germanium lens and single crystal Ge ingot , we have a strong advantage in providing single crystal wafer to micro-electronics and opto-electronics industry in diameter range from 2 inch to 6inch .

Ge wafer is an elemental and popular semiconductor material , due to its excellent crystallographic properties and unique electric properties , Ge wafer is widly used in Sensor , Solar cell and Infrared optics applications .

We can provide low dislocation and epi ready Ge wafers to meet your unique requirement. Ge wafer is produced as per semiconductor,with a good quality control system ,  ZMKJ Is dedicated to providing clean and high quality Ge wafer products .

we can offers both electronics grade and IR grade Ge wafer , please contact us for more Ge product information.



In the range of 2-12 μm, germanium is the most commonly used material for the production of spherical lenses and windows for high efficiency infrared in imaging system. Germanium has a high refractive index (about 4.0 through 2-14μm band), usually do not need to be modified due to its low chromatic aberration in low power imaging systems.



Diameter
0.2-150mm
Thickness
0.1-100mm
Dimension tolerance
+/-0.1mm or +/-0.02mm
Surface quality (scratch & dig)
60/40, 40/20 or better
Clear aperture
>85%, >90%
Surface accuracy
L/10 L/2 L
Parallelism
+/-3' ,+/-30''
Bevel
0.1~0.3mm x 45 degree
Coating
AR, BBAR or Custom

OEM Dia 25.4mm Single Crystal Ge optical lens 0

OEM Dia 25.4mm Single Crystal Ge optical lens 1

OEM Dia 25.4mm Single Crystal Ge optical lens 2

OEM Dia 25.4mm Single Crystal Ge optical lens 3OEM Dia 25.4mm Single Crystal Ge optical lens 4

OEM Dia 25.4mm Single Crystal Ge optical lens 5

OEM Dia 25.4mm Single Crystal Ge optical lens 6

OEM Dia 25.4mm Single Crystal Ge optical lens 7
