TiO2 Titanium Dioxide Crystal 10x10x0.5mmt 1sp/ 2sp Single Double Polishing

TiO2 Titanium Dioxide Crystal 10x10x0.5mmt 1sp/ 2sp Single Double Polishing

  • High Light

    magnesium oxide

    ,

    wafer substrate

  • Material
    TiO2 Crystal Substrate
  • Common Size
    10x10 20x20
  • Orientation
    <100><110><111>
  • Color
    Colorless
  • Application
    High Temperature Superconducting Junction Technology
  • Place of Origin
    china
  • Brand Name
    zmkj
  • Model Number
    sto wafers
  • Minimum Order Quantity
    10pcs
  • Price
    by case
  • Packaging Details
    single wafer package in 100-grade cleaning room
  • Delivery Time
    2-4weeks
  • Payment Terms
    T/T, Western Union, MoneyGram
  • Supply Ability
    1000pcs

TiO2 Titanium Dioxide Crystal 10x10x0.5mmt 1sp/ 2sp Single Double Polishing





TiO2 Crystal(Titanium Dioxide)Crystal by 10x10x0.5mmt 1sp/ 2sp





Product Name: Rutile (TiO2) crystal substrate

Product Description: Rutile (TiO2) large birefringence, large refractive index, is a method for spectral prism devices such as optical isolators and the polarization beam splitter and a very good material, compared with YVO4, TiO2 crystal better physical and chemical stability, Our high quality single crystal TiO2 rods and polished components widely used in optical isolators and special prism.

Technical parameters:

Specifications:

Typical dimensions: 2.6x2.6 x10 mm; 4x4x10 mm; 10x10x0.5 mm;

Size + / - 0.02 mm; flatness <l/10; roughness <10/5;

Parallelism <15 "; vertical <15"

Note: Can be customized according to the special orientation and size.

Standard Packaging: 1000 clean room, 100 clean bag or single box packaging





Major capability parameter
Crystal structure M4
Unit cell constant a=4.5936Å c=2.9582 Å
Density 4.26(g/cm3)
Melt point 1870℃
Dielectric constants dη/dT:a:-0.72×10­6/k c:-0.42×10-6/k
Linear expansion coefficient a:7.14×10­6 c:9.19×10­6
Hardness 7(mohs)
Polishing Single or double
Size 5×5×10mm,5×10×10mm,10×10×0.5mm
Polishing Single or double
Pack 100 clean bag,1000 exactly clean bag



Application:

Rutile has a large birefringence and a large refractive index. It is a good material for spectral prisms and polarizing devices (such as optical isolators and beam splitters). Compared with YVO4, TiO2 crystals have better physicochemical stability.



TiO2 Titanium Dioxide Crystal 10x10x0.5mmt 1sp/ 2sp Single Double Polishing 0

OUR RELATED PRODUCTS

TiO2 Titanium Dioxide Crystal 10x10x0.5mmt 1sp/ 2sp Single Double Polishing 1

FAQ


Q. Do you have any stock of wafer or ingots?

yes,aslike 3inch,4inch commen size substrates wafers are in stocks.


Q. Where is your company located?
Our company located in shanghai,China. factory is in wuxi city.

Q. How long will take to get the products?
Generally it will take 1~4 weeks to process and then delivery.

It is depend on the quantity and the size of the products.



Q: How about pay term & delivery ?

T/T 50%deposit and left part before delivery by FOB .
