Green Laser Sapphire Crystal Artificial Single For Watch Glass Customized Size
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | ZMKJ |
| Model Number: | Green sapphire（Al2O3 ) |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5pcs |
|---|---|
| Price: | 20-500usd/pcs by case |
| Packaging Details: | packed in Capacitor paper +Sponge paper+paper case |
| Delivery Time: | in 3-5weeks |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 500pcs per month |
|
Detail Information |
|||
| Material: | Doped Al2O3 Crystal | Color: | Green |
|---|---|---|---|
| Orientaion: | C-axis Or A-axis | Size: | 10x10x5mmt Or Customized |
| Applications: | OPtical ＆ Gems Or For Laser | Growth Method: | Cz Method |
| Purity: | 99.99％ | ||
| High Light: | ruby block,sapphire material |
||
Product Description
Fe3+ Ti+ / Cr+ doped Blue / Green / Red/ Yellow colored sapphire Al2O3 crystal ＆Ruby lens for laser
1.About the color
The main component of sapphire is alumina (Al2O3). The simple alumina single crystal is transparent and colorless, but it penetrates into the growing sapphire by different color elements, thus making the sapphire crystals different colors.
When artificially doped with iron ions (Fe3+) and titanium ions (Ti+), the crystals will appear blue sapphire (Blue Sapphire).
When the crystal is doped with iron (Fe3+) and cobalt (Co2+), vanadium (V3+) the crystal will appear green.
( Green Sapphire)
When the crystal contains chromium ions (Cr3+), or (Ti+), the crystal will appear red and become to be Ruby.
When the crystal contains nickel ions (Ni3+), the crystal will appear yellow and become Yellow Sapphire.
Green Sapphire Sapphire, with its Mohs hardness score of 9, second only to diamond, is one of themost valuable and wearable of all gemstones. Famed for its brilliance and rich blue color, sapphireactually occurs in a wide range of colors, including pink, yellow and green.
Sapphire is every color ofcorundum except for red, which is ruby.
About the Material
| Product Name: | Fe3+ Ti+ Cr3+ sapphire sapphire crystal | ||||||||||||||||||||||
| Product Description: | Sapphire (Sapphire, also known as white stones, the formula Al2O3) has a very good thermal properties, excellent electrical characteristics and dielectric properties, and anti-chemical corrosion, it is high temperature, thermal conductivity, high hardness, infrared transparent, good chemical stability. Widely used in high-temperature infrared window materials and III-V nitride epitaxial film substrate and a variety ofmaterials to meet the growing blue, purple, white light-emitting diode(LED) and blue laser (LD) needs, Branch Crystal company specializing in the production of high quality polished sapphire crystal and epitaxial substrates will provide you with a lot of high quality and low price monocrystalline substrate. | ||||||||||||||||||||||
| Technical parameters: |
|
||||||||||||||||||||||
| Specifications: |
C, A, Tolerance: + / -1 degrees |
||||||||||||||||||||||
| Standard Packaging: | 1000 clean room or single box packaging |
Applications:
• Laser spectroscopy
• LIDARs
• Medial laser
Meta-Photonics Ti:sapphire
• Grown by Thermal Exchange Method
• Figure of Merit (FOM) value: 150-350
• Absorption coefficient:0.3~3.5cm-1
• Maximal Size: dia150mm
Custom design prouction (special doping concentration, shape, coating) is available
Products Detail:
Pictures sample specification
Grade: optical grade without bubble,
size:(pictures sizes) ,dia50.8x1.0mmt,(dia1~50mm ok),10x10x5mmt
Orientation:C(0001)±3°,
surface:polished/lapped either ok
color grade:(picture) : Green Blue /Red
After-sale Service-
1. Our Customer service will begin to track the product processing every day until you receive the goods and verify the product quality when you finish the payment.
2. Online via SKYPE :Also through mail, voice phone, message could contact us at any time!
3. Follow up the case, record the entire process. Solution will be provide with 24 hours.
4. Collect and record all the voice from each customer respond , suggestion, requirement.
5. All products have half of year warranty.If there is no man-made problem,we will replace or repair for your freely.
