Titanium Sapphire Crystal Optical Windows High Hardness Customized Size Excellent Transparency For Optical Purpose
Product Details:
| Place of Origin: | China |
| Brand Name: | ZMSH |
| Model Number: | Sapphire optical window doped Titanium |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5 pcs |
|---|---|
| Price: | by case |
| Delivery Time: | 2-4weeks |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 50000pcs per month |
|
Detail Information |
|||
| Ti2O3 Concentration: | 0.03-0.25 Wt % | Orientation: | Optical Axis C Normal To Rod Axis |
|---|---|---|---|
| Color: | Pink | Size: | Up To 20 Mm Dia And Up To 130 Mm Length |
| Figure Of Merit: | > 150 (>300 Available On Special Requests) | Chemical Formula: | Ti3+:Al2O3 |
| End Configurations: | Flat/flat Or Brewster/Brewster Ends | ||
| Highlight: | Excellent Transparency Sapphire Optical Windows,Customized Size Sapphire Optical Windows,High Hardness Sapphire Optical Windows |
||
Product Description
Titanium Sapphire Crystal Optical Windows High Hardness Customized Size Excellent Transparency for Optical Purpose
Product abstract
Our titanium-doped sapphire Windows (Ti: sapphire crystal), with high transparency and good optical clarity, are well known for their excellent performance. These Windows are made from a combination of high-quality titanium and sapphire crystal, which can be widely used in a variety of optical applications and play an excellent performance advantage. With excellent transparency and excellent optical clarity, our titanium-doped sapphire crystals guarantee accurate observation and precise measurement in applications, making them the ideal and preferred choice for high-precision instruments, advanced scientific equipment and advanced optical systems. Choose our titanium sapphire Crystal optical window pieces to experience the difference with our optical window pieces, where the clarity meets the durability and unmatched performance.
Product details
Product parameter
|
Product |
Titanium (Ti+) doped sapphire optical windows |
| Chemical formula | Ti3+: Al2O3 |
| Crystal structure | Hexagonal |
| Lattice constants | a=4.748, c=12.957 |
| Density | 3.98 g/cm3 |
| Mohs hardness | 9.0 |
| Thermal conductivity | 0.11 cal/(°C×sec×cm) |
| Specific heat | 0.10 cal/g |
| Melting point 2050°C | 2050°C |
| Laser action | 4-Level Vibronic |
| Fluorescence lifetime | 3.2 µsec (T=300K) |
| Tuning range | 660-1050 nm |
| Absorption range | 400-600 nm |
| Emission pea | 795 nm |
| Absorption peak | 488 nm |
| Refractive index | 1.76 @ 800 nm |
Product application
-
Enhanced Performance: By combining exceptional transparency, optical clarity, and durability, our windows enhance the performance and longevity of optical systems, ensuring reliable operation in critical applications.
-
Laser Systems: Employed as protective windows or optical components in laser systems for research, medical, industrial, and military applications due to their high durability and optical clarity.
-
Scientific Instruments: Used in spectrometers, microscopes, telescopes, and other scientific instruments requiring precise optical components for accurate observation and analysis.
-
Optical Sensors: Utilized in optical sensors for measuring light intensity, wavelength, or other optical parameters in scientific research, environmental monitoring, and industrial applications.
-
Excellent Transparency: Our windows are crafted from high-quality sapphire crystal, offering exceptional transparency that allows for clear observation and measurement.
-
Versatility: Our Titanium Sapphire Crystal Windows are suitable for a wide range of applications, including scientific instruments, optical sensors, laser systems, aerospace equipment, and more.
-
Optical Sensors: Utilized in optical sensors for measuring light intensity, wavelength, or other optical parameters in scientific research, environmental monitoring, and industrial applications.
-
Precision: Designed for precision optical applications, our windows maintain tight tolerances and optical specifications, enabling precise measurements and observations.
-
High-End Watches: Employed as watch crystals in luxury timepieces for their scratch-resistant and optically clear properties, enhancing the durability and aesthetics of the watch.
-
Underwater Cameras: Incorporated into underwater camera housings to protect the camera lens while maintaining optical clarity for underwater photography and videography.
-
Optical Windows: Used as optical windows in various optical systems, including cameras, projectors, and sensors, to provide protection while maintaining optical performance.
-
Medical Devices: Used in medical devices such as endoscopes, imaging systems, and laser surgery equipment for high-precision optical imaging and diagnostics.
-
Aerospace Equipment: Integrated into aerospace instruments and equipment for navigation, communication, remote sensing, and imaging applications, where reliability and performance are critical
Q&A
1. What's titanium doped sapphire?
Titanium-sapphire refers to the lasing medium, a crystal of sapphire (Al2O3) that is doped with Ti3+ ions. A Ti:sapphire laser is usually pumped with another laser with a wavelength of 514 to 532 nm, for which argon-ion lasers (514.5 nm) and frequency-doubled Nd:YAG, Nd:YLF, and Nd:YVO lasers (527–532 nm) are used.
2. What's the pulse duration of Ti:sapphire?
With a pulse duration of less than 8 fs, this laser provides an exceptionally high peak power of more than 700 kW and a large spectral bandwidth spanning more than 200 nm at -10 dB.
